HP (Hewlett-Packard) HP T1500 G3 manual: Chapter 6 UPS Maintenance. Do not discard the UPS or the UPS batteries in the trash. This product contains sealed.
HP T750 G2 UPSPhysical specificationsDescription |
|---|
150 x 333 x 193 mm (5.9 x 13.1 x 7.6 in) | 310 x 257 x 442 mm (12.2 x 9.9 x 17.4 in) | 12.7 kg (28.1 lbs) | 14 kg (30.9 lbs) |
Electrical specificationsFeature |
|---|
T750 G2 - NA/JPN | Operating Voltage Settings | NOTE: Part Number AF446A is user selectable for 100 V, 110 V, or 120 V via dip switch setting on the back of the unit. | NA: 750 VA / 500 W | Input Connection | Output Connection | Load Segments | T750 G2 - INTL | Operating Voltage Settings | NOTE: Part Number AF447A is user selectable for 220 V, 230 V, or 240 V via dip switch setting on the back of the unit. | 750 VA / 500 W | IEC- 60320 C13 | (4) IEC 320 C14 | 1 | NOTE:Click here to locate which Operating Systems are supported. |
HP T750 G4 UPSPhysical specificationsDescription |
|---|
Unit Dimensions (W x D x H) | Shipping Dimensions | Unit Weight | Shipping Weight |
Electrical specificationsFeature |
|---|
T750 G4, NA/JP | Operating Voltage Settings | User selectable for 100 V/110 V/120 V via dip switch setting on back of unit | 750 VA/500 W | Attached 6 foot power cord with NEMA 5-15P | (4) NEMA 5-15R | 1 | NOTE:Click here to locate which Operating Systems are supported available at http://www.hp.com/products/powermanager |
HP T1000 G3 UPSPhysical specificationsDescription |
|---|
150 x 333 x 193 mm (5.9 x 13.1 x 7.6 in) | 310 x 257 x 442 mm (12.2 x 9.9 x 17.4 in) | 12.7 kg (28.1 lbs) | 14 kg (30.9 lbs) |
Electrical specificationsFeature |
|---|
T1000 G3 - NA/JPN | Operating Voltage Settings | NOTE: Part Number AF448A is user selectable for 100 V, 110 V, or 120 V via dip switch setting on the back of the unit. | NA: 1000 VA / 670 W | Input Connection | Output Connection | Load Segments | T1000 G2 - INTL | Operating Voltage Settings | NOTE: Part Number AF449A is user selectable for 220 V, 230 V, or 240 V via dip switch setting on the back of the unit. | 1000 VA / 670 W | IEC 320 C13 | (6) IEC 320 C14 | 1 | NOTE:Click here to locate which Operating Systems are supported. |
HP T1000 G4 UPSPhysical specificationsDescription |
|---|
Unit Dimensions (W x D x H) | Shipping Dimensions | Unit Weight | Shipping Weight |
Electrical specificationsFeature |
|---|
T1000 G4, NA/JP | Operating Voltage Settings | User selectable for 100 V/110 V/120 V via dip switch setting on back of unit | NA: 1000 VA/670 W | Attached 6 foot power cord with NEMA 5-15P | (6) NEMA 5-15R | 1 | NOTE:Click here to locate which Operating Systems are supported available at http://www.hp.com/products/powermanager |
HP T1500 G3 UPSPhysical specificationsDescription |
|---|
150 x 390 x 193 mm (5.9 x 15.4 x 7.6 in) | 310 x 257 x 518 mm (12.2 x 9.9 x 17.4 in) | 17.0 kg (37.4 lbs) | 18 kg (40.5 lbs) |
Electrical specificationsFeature |
|---|
T1500 G3 - NA/JPN | Operating Voltage Settings | NOTE: Part Number AF450A is user selectable for 100 V, 110 V, or 120 V via dip switch setting on the back of the unit. | NA: 1400 VA / 950 W | Input Connection | Output Connection | Load Segments | T1500 G3, INTL | Operating Voltage Settings | NOTE: Part Number AF451A is user selectable for 220 V, 230 V, or 240 V via dip switch setting on the back of the unit. | 1400 VA / 950 W | IEC 320 C13 | (6) IEC 320 C14 | 1 | NOTE:Click here to locate which Operating Systems are supported. |
HP T1500 G4 UPSPhysical specificationsDescription |
|---|
Unit Dimensions (W x D x H) | Shipping Dimensions | Unit Weight | Shipping Weight |
Electrical specificationsFeature |
|---|
T1500 G4, NA/JP | Operating Voltage Settings | User selectable for 100 V/110 V/120 V via dip switch setting on back of unit | 1400 VA/950 W | Attached 6 foot power cord with NEMA 5-15P | (6) NEMA 5-15R | 1 | NOTE:Click here to locate which Operating Systems are supported available at http://www.hp.com/products/powermanager |
Estimated backup times chart (in minutes)Load, percent | Estimated battery runtime at 100% battery charge |
|---|
50% | 15 minutes | 500 | T1000 G3 | 335 | 100% | 5 minutes | 50% | 15 minutes | 950 | T750 G4 | 250 | 100% | 5 minutes | 50% | 15 minutes | 670 | T1500 G4 | 475 | 100% | 5 minutes | NOTE: Backup times are estimated for typical applications. Actual performance will depend on load and battery conditions. |
