The AN/PRC-152 Multiband Handheld Radio (Harris Falcon III) is a portable, compact, tactical software-definedcombat-net radio manufactured by Harris Corporation.[1] It is compliant without waivers to the Joint Tactical Radio System (JTRS) Software Communications Architecture (SCA).[2][3] It has received NSA certification for the transmission of Top Secret data.
The designation AN/PRC translates to Army/Navy Portable Radio used for two way Communications, according to Joint Electronics Type Designation System guidelines.
Post: What I see is 2014 Fraud Examiner's manual, is there going to be a new one coming up for 2015? If yes, what's the timeline? The 2015 Fraud Examiners Manual, International Edition is scheduled to be released sometime mid-April. If I take the exam based on the 2014 Fraud Manual, will it help or do I wait for the 2015 manual to come through?Response: Good afternoon Sarangarajan,Thank you for your question. The 2014 version is still a valid version and completely capable of preparing your for the CFE Exam. Fraud examiners manual download free.
The Falcon III ® AN/PRC-152 single-channel multiband, Secured by the Harris Sierra II software-programmable encryption module, Operator s manual (included) Ulukhaktok NT, NT Canada, X1A 6L3 The AN/PRC-152 multiband handheld Harris can configure AN/PRC-152 based systems to fit a wide variety of needs. Harris prc 152 user manual - free pdf ebook harris prc 152 user manual at greenbookee.org - Download free pdf files,ebooks and documents of harris prc 152 user manual An/prc-152 handheld radio - olive-drab.com AN/PRC-152 Handheld Radio information and photos from Olive-Drab.com An prc 152 technical manual compiled pdf, doc, ppt. Harris prc 152 user manual - free pdf ebook harris prc 152 user manual Direct Download Also Try: harris prc 152 user manual harris prc 152 pocket guide harris prc 117g manual harris 152 radio manual. Harris Prc 152 User Manual Harris Prc 152 User Manual An Prc 152 Harris Operations Manual booklad.org an prc 152 harris operations manual book. Harris Falcon III® family of radios delivers superior command and control. Handheld, manpack, in-vehicle. PRC-152A PRC-117G PRC-160 PRC-163 SINCGARS. Harris Prc 152 User Manual An Prc 152 Harris Operations Manual booklad.org an prc 152 harris operations manual book results. Follow: Tweet: The Peoples Republic of. Today the Harris AN/PRC-152 The Falcon III AN/PRC-152 single I am looking for operators manual for an AN/ PRC I am looking for operators manual for an AN/PRC 152 (1 answer.
- 2Specifications
Users[edit]
The AN/PRC-152 radio is currently in use with the US Navy Explosive Ordnance Disposal (EOD) teams in their MRAPJERRV vehicles.[4] As of 2005, 1,300 radios have also been fielded in vehicles by the US Army.[5] and more than 8,600 have been fielded by the U.S. Marines.[6] An undetermined number are in use by the US Air Force in Iraq and Afghanistan.[7] More recently the radio was photographed with Prince Harry, then a 23-year-old second lieutenant in the Household Cavalry of the British Army. He was responsible for providing cover for troops on the frontline as a Forward Air Controller (FAC) employing the AN/PRC-152 Multiband Handheld and other systems.[8]
An Prc 152 Training Manual
Specifications[edit]
General[edit]
- Frequency Range: 30 to 511.99 MHz[9]
- Presets: 99
- Transmission Modes: FM, AM, PSK, CPM
- Tuning Resolution: 10 Hz
Transmitter[edit]
- Output Power: 250 mW to 5 W / VSAT 10 W
- Harmonic Suppression: –47 dBc
- Frequency Stability: +/- 2.5 ppm
Receiver[edit]
- FM Sensitivity -116 dBm (12 dB SINAD)
- Adjacent Channel Greater than 55 dB Rejection
Harris An Prc 152 Manual
Interoperability[edit]
- Crypto Modes KY-57/VINSON, ANDVT/KYV-5, KG-84C, FASCINATOR, AES[1]
- Fill devices: AN/CYZ-10 DTD, AN/PYQ-10SKL (Supports DS-101, DS-102 and Mode 2/3)
- Radios
- AN/PRC-119A/B
- AN/PRC-117G
- RF-310
- Optional internal GPS
Interfaces[edit]
Harris Falcon Iii An Prc-152 User Manual Video
- External Data: RS-232, RS-422, MIL-STD-188-114A
- Remote control: USB, RS-232
- Antenna: 50 Ohm TNC
- Audio: Six-pin Standard
Physical Dimensions[edit]
- 64(68.6 GPS) x 234 x 43 mm 2.5(2.7 GPS) W x 9.2 H x 1.7 D inches (with battery)
- Weight: 1.22 kg 2.7 lb (with battery and GPS)
Environmental[edit]
- Temperature: -31 °C to 60 °C
- Immersion: 2 Meter
- Test Method: MIL-STD-810F
- Finish: CARCGreen, CARCKhaki
Key Features[edit]
- SCA v2.2
- Sierra II Programmable Crypto
- Built-in Speaker/Mic
- Full Numeric Keypad
- NVG Compatible Display
- Embedded GPS (optional)
Waveforms[edit]
- VHF/UHFAM/FM (aka VULOS)
- MIL-STD-188-181B Advanced Narrowband Digital Voice Terminal (ANDVT) and 56 kbit/s data
- HAVE QUICK II
- High performance waveform (HPW)
- A software option supports Project 25 (APCO-25), used by federal, state, province and local public safety agencies in North America, including Triple DES encryption.
